ShelterPro Stainless Steel Chimney cover is constructed of 100% 304 stainless steel and built to withstand the toughest conditions. Ideal for oil, coal, or heavy wood burners. High quality construction includes a 24 gauge stainless steel hood with scalloped corners and roll-formed edges, 18 gauge 3/4 inch expanded stainless steel mesh and 16 gauge stainless steel base. Using slotted hex-head bolts, the unique corner mounting attachment design of a ShelterPro chimney cover provides the securest possible fit to a masonry flue tile. Lifetime limited warranty.
Chimney Cap Sizing:
Â
|  | MPN | OUTSIDE TILE SIZE | FITS OUTSIDE TILE | APPROX. LBS. |
| NUMBERÂ | NUMBERÂ | (IN INCHES)Â | DIMENSIONÂ | STAINLESSÂ |
| STAINLESSÂ | STAINLESSÂ | Â | (IN INCHES)Â | Â |
| Â | Â | Â | Â | Â |
| 150499 | SCSS99 | 9 x 9Â | 7 1/2 x 7 1/2 to 9 1/2 x 9 1/2Â | 5 |
| 150493 | SCSS913 | 9 x 13 | 7 1/2 x 11 1/2 to 9 1/2 x 13 1/2Â | 5.5 |
| 150426 | SCSS918 | 9 x 18 | 7 1/2 x 16 1/2 to 9 1/4 x 18Â 1/4 | 8 |
| 150433 | SCSS1313 | 13 x 13Â | 11 1/2 x 11 1/2 to 13 1/2 x 13 1/2Â | 7 |
| 150438 | SCSS1318 | 13 x 18Â | 11 1/2 x 16 1/2 to 13 1/2 x 18Â | 9 |
| 150488 | SCSS1818 | 18 x 18Â | 16 1/2 x 16 1/2 to 18 x 18Â | 10 |
Product Info:
- HY-C Single Flue Cap Installation Instructions (PDF, 229KB)Â
